Grey/Silver/Grey 10
Price range: $199.00 through $980.00
Silver series products are constructed by sputtering thin layers of precious metals onto film. This results in a line of reflective films that provide high privacy and heat rejection while maintaining optical clarity.
Silver series products are constructed by sputtering thin layers of precious metals onto film. This results in a line of reflective films that provide high privacy and heat rejection while maintaining optical clarity.
Key Benefits
- Reflecting heat instead of absorbing it results in higher heat rejection and improved indoor comfort
- Increases occupant privacy while enhancing the building exterior
- High heat rejection and long warranty terms combine for attractive commercial payback times
- UV blockers protect people and property from damaging UV rays
| Specification | Grey/Silver/Grey 10 | |
|---|---|---|
| Visible light transmittance % | 5% | |
| Visible light reflectance (exterior) % | 10% | |
| Visible light reflectance (interior) % | 10% | |
| Solar heat gain coefficient | .31 | |
| Total solar energy rejected % | 69% | |
| UV Tdw-ISO @ 300 to 700 nm % | 4% | |
| UV light blocked (300 to 380 nm) % | >99% | |
| Fade Reduction % | 95% |
Performance Notes:
- Performance results are calculated using NFRC methodology and LBNL Window software, and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and are subject to normal manufacturing variances
- Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
| Weight | 18 lbs |
|---|---|
| Dimensions | 72 × 6 × 6 in |
| Roll Size | 36"x25', 36"x50', 36"x75', 36"x100', 48"x25', 48"x50', 48"x75', 48"x100', 60"x25', 60"x50', 60"x75', 60"x100' |
